Soyuz-2.1a / Fregat Baikonur launch 2021-03-22T06:07 UTC

Satellites & Observations Launches
47

Hi

Pocketqubes are free now from UNISAT-7 this morning!
STECCO and DIY-1 were copied.

Gustavo.

3 Likes
48

After 5 new TLE sets (all TBA: TO BE ASSIGNED) and in total 16 TLE sets from spacetrack we have the current results (with bold the chosen in DB and Network):

  • UNISAT-7: one of OBJECT H(47939), OBJECT J(47940)

  • BCCSAT-1: no reception changed to follow OBJECT H(47939)

  • FEES: no reception changed to follow OBJECT J(47940)

  • DIY-1: one of OBJECT N(47944),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947)

  • SMOG-1: no reception changed to follow OBJECT H(47939)

  • STECCO: one of OBJECT H(47939), OBJECT J(47940), OBJECT N(47944),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947)

  • NANOSATC-BR2: one of OBJECT G(47938), OBJECT K(47941)

  • KMSL: one of OBJECT G(47938), OBJECT K(47941)

  • CANYVAL-C 1U: no reception continue to follow OBJECT G(47938)

  • CANYVAL-C 2U: no reception continue to follow OBJECT G(47938)

  • BEESAT-5: none of the objects fits, we will follow OBJECT G(47938) until TLE sets in https://git.tu-berlin.de/rft/com/tle/-/raw/master/BEESAT-5-6-7-8.txt have epoch greater than 21082.59536012

  • BEESAT-6: none of the objects fits, we will follow OBJECT G(47938) until TLE sets in https://git.tu-berlin.de/rft/com/tle/-/raw/master/BEESAT-5-6-7-8.txt have epoch greater than 21082.59536012

  • BEESAT-7: none of the objects fits, we will follow OBJECT G(47938) until TLE sets in https://git.tu-berlin.de/rft/com/tle/-/raw/master/BEESAT-5-6-7-8.txt have epoch greater than 21082.59536012

  • BEESAT-8: none of the objects fits, we will follow OBJECT G(47938) until TLE sets in https://git.tu-berlin.de/rft/com/tle/-/raw/master/BEESAT-5-6-7-8.txt have epoch greater than 21082.59536012

  • CUBESX-SIRIUS-HSE: one of OBJECT G(47938), OBJECT K(47941)

  • CUBESX-HSE: one of OBJECT G(47938), OBJECT K(47941)

  • ORBICRAFT-ZORKIY: one of OBJECT G(47938), OBJECT K(47941)

  • SIMBA: one of OBJECT G(47938), OBJECT K(47941)

  • GRBALPHA: one of OBJECT G(47938), OBJECT K(47941)

  • CHALLENGEONE: no reception continue to follow OBJECT G(47938)

  • KSU-CUBESAT: one of one of OBJECT G(47938), OBJECT K(47941)

No identification as we expect TBA TLE sets to be assigned and also more TLE sets.

49

For your information BCCSAT-1 use GMSK 4K8 G3RUH
Thank you so much

1 Like
50

Any public source for that?

EDIT I’m asking because in https://mailman.amsat.org/hyperkitty/list/amsat-bb@amsat.org/message/EWJNTVQUHYFEM5HT5SJSNYKQ3S3KHPWT/ there isn’t any info about it.

51

@fredy This link

1 Like
52

Very strong downlink from STECCO on 435.800 1533utc

-Scott, K4KDR

2 Likes
53

DIY-1 is sending RTTY 100 BD 7N2 SHIFT 450

SATGNOS stations are receiving in wrong CW mode, please correct to USB mode
for properly decodification.

54

The transmitter is already created but not used as we don’t have a special flowgraph(gnuradio script) for USB mode, this is why we currently use the CW one. If we use the USB transmitter, SatNOGS stations will run a generic FM flowgraph.

1 Like
55

Thanks for the info!

56

ChallengeOne first satellite of Tunisia has been received and for now it fits the TBA TLE set of OBJECT AA(47956).

57

Current status and fits of spacetrack TLE sets (still several TBA: TO BE ASSIGNED and missing ones), there several changes from the previous fits, as the objects are not assigned is expected to be swapped (with bold the chosen to follow in DB and Network):

  • UNISAT-7: one of OBJECT N(47944),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947)
    • After a period of no signal is again transmitting, changed to follow OBJECT N(47944)
  • BCCSAT-1: no reception changed to follow OBJECT H(47939)
  • FEES: no reception changed to follow OBJECT J(47940)
  • DIY-1: OBJECT H(47939)
    • Changed to follow OBJECT H(47939)
  • SMOG-1: OBJECT H(47939)
    • Received and remains to follow OBJECT H(47939)
  • STECCO: one of OBJECT H(47939), OBJECT J(47940), OBJECT M(47943), OBJECT N(47944),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947)
    • No signal received since 2021-03-24 23:55, remains to follow OBJECT H(47939)
  • NANOSATC-BR2: one of OBJECT U(47950), OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
    • Changed to follow OBJECT V(47951)
  • KMSL: one of OBJECT U(47950), OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT Z(47955), OBJECT G(47938), OBJECT K(47941)
    • Changed to follow OBJECT U(47950)
  • CANYVAL-C 1U: no reception continue to follow OBJECT G(47938)
  • CANYVAL-C 2U: no reception continue to follow OBJECT G(47938)
  • BEESAT-5: some objects fits but we will use TLE from https://git.tu-berlin.de/rft/com/tle/-/raw/master/BEESAT-5-6-7-8.txt as it fits better
  • BEESAT-6: some objects fits but we will use TLE from https://git.tu-berlin.de/rft/com/tle/-/raw/master/BEESAT-5-6-7-8.txt as it fits better
  • BEESAT-7: some objects fits but we will use TLE from https://git.tu-berlin.de/rft/com/tle/-/raw/master/BEESAT-5-6-7-8.txt as it fits better
  • BEESAT-8: some objects fits but we will use TLE from https://git.tu-berlin.de/rft/com/tle/-/raw/master/BEESAT-5-6-7-8.txt as it fits better
  • CUBESX-SIRIUS-HSE: one of OBJECT U(47950), OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
    • Changed to follow OBJECT W(47952)
  • CUBESX-HSE: one of OBJECT U(47950), OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
    • Changed to follow OBJECT V(47951)
  • ORBICRAFT-ZORKIY: one of OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT Z(47955), OBJECT G(47938), OBJECT K(47941)
    • Changed to follow OBJECT X(47953)
  • SIMBA: one of OBJECT U(47950), OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT Z(47955), OBJECT G(47938), OBJECT K(47941)
    • Changed to follow OBJECT W(47952)
  • GRBALPHA: one of OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
    • Changed to follow OBJECT W(47952)
  • CHALLENGEONE: one of OBJECT AA(47956) OBJECT U(47950), OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT Z(47955), OBJECT G(47938), OBJECT K(47941)
    • Received and changed to follow OBJECT AA(47956)
  • KSU-CUBESAT: one of OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT G(47938), OBJECT K(47941)
    • Changed to follow OBJECT X(47953)

No identification as we expect TBA TLE sets to be assigned and also more TLE sets, you can notice that some satellites fit on the same object. Some of the satellites fit also objects with NORAD ID 88810 and 88812 that may be some of the missing TLE sets.

EDIT: I forgot to thank @cgbsat that confirmed independently with strf observations the status and some of the fits above and found out about the 888XX TLE sets.

3 Likes
58

BCCSAT-1 has just been received: https://network.satnogs.org/observations/3836112/

Interesting how the CW is transmitted in relation with the GMSK signal.

Currently it fits better OBJECT N(47944), as the UNISAT-7.

2 Likes
59

The CW appears to be performed on whatever tone the GMSK packet finished up on…

60

Some changes on TLE sets we follow after @PE0SAT strf analysis:

For GRBAPLHA we now follow OBJECT G(47938)
For KSU-CUBESAT we now follow OBJECT Y(47954)

1 Like
61

Current status and fits of spacetrack TLE sets (all TLE sets assigned to OBJECTS but we have missing ones for this launch), no major changes(with bold the chosen to follow in DB and Network):

  • UNISAT-7: one of OBJECT H(47939), OBJECT J(47940), OBJECT N(47944),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947)
    • Added two TLE sets OBJECT H(47939) and OBJECT J(47940)
  • BCCSAT-1: one of OBJECT J(47940), OBJECT Q(47946), OBJECT R(47947)
    • Changed to follow OBJECT R(47947)
  • FEES: no reception changed to follow OBJECT N(47944)
  • DIY-1: OBJECT M(47943)
    • Changed to follow OBJECT M(47943)
  • SMOG-1: OBJECT M(47943)
    • Changed to follow OBJECT M(47943)
  • STECCO: one of OBJECT H(47939), OBJECT J(47940), OBJECT M(47943), OBJECT N(47944),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947)
    • No signal received since 2021-03-24 23:55, changed to follow OBJECT M(47943)
  • NANOSATC-BR2: one of OBJECT U(47950), OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
    • Changed to follow OBJECT W(47952)
  • KMSL: one of OBJECT U(47950), OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT G(47938), OBJECT K(47941)
    • Rejected OBJECT Z(47955)
  • CANYVAL-C 1U: no reception continue to follow OBJECT G(47938)
  • CANYVAL-C 2U: no reception continue to follow OBJECT G(47938)
  • BEESAT-5: one of OBJECT U(47950), OBJECT V(47951)
    • Changed to follow OBJECT U(47950)
  • BEESAT-6:one of OBJECT U(47950), OBJECT V(47951)
    • Changed to follow OBJECT U(47950)
  • BEESAT-7: one of OBJECT U(47950), OBJECT V(47951)
    • Changed to follow OBJECT U(47950)
  • BEESAT-8: one of OBJECT U(47950), OBJECT V(47951)
    • Changed to follow OBJECT U(47950)
  • CUBESX-SIRIUS-HSE: one of OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
    • Rejected OBJECT U(47950)
  • CUBESX-HSE: one of OBJECT U(47950), OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
  • ORBICRAFT-ZORKIY: one of OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT G(47938), OBJECT K(47941)
    • Rejected OBJECT V(47951) and OBJECT Z(47955)
  • SIMBA: one of , OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
    • Rejected OBJECT U(47950), OBJECT V(47951), OBJECT Y(47954) and OBJECT Z(47955),
  • GRBALPHA: one of OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
    • Rejected OBJECT V(47951) and change to follow OBJECT G(47938)
  • CHALLENGEONE: one of OBJECT AA(47956), OBJECT U(47950)
    • Rejected OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT Z(47955), OBJECT G(47938) and OBJECT K(47941)
  • KSU-CUBESAT: one of OBJECT Y(47954), OBJECT Z(47955)
    • Rejected OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941) and changed to follow OBJECT Y(47954)

No identification as we expect more TLE sets.

2 Likes
62
Satellite Norad Follow Other Candidates Notes
UNISAT-7 OBJECT N(47944) OBJECT H(47939), OBJECT J(47940),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947) Added two TLE sets OBJECT H(47939) and OBJECT J(47940)
BCCSAT-1 OBJECT R(47947) OBJECT J(47940), OBJECT Q(47946) Changed to follow OBJECT R(47947)
FEES OBJECT N(47944) no reception changed to follow OBJECT N(47944)
DIY-1 OBJECT M(47943) Changed to follow OBJECT M(47943)
SMOG-1 OBJECT M(47943) Changed to follow OBJECT M(47943)
STECCO OBJECT M(47943) OBJECT H(47939), OBJECT J(47940), OBJECT N(47944),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947) No signal received since 2021-03-24 23:55, changed to follow OBJECT M(47943)
NANOSATC-BR2 OBJECT W(47952) OBJECT U(47950), OBJECT V(47951), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941) Changed to follow OBJECT W(47952)
KMSL OBJECT U(47950) OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT G(47938), OBJECT K(47941) Rejected OBJECT Z(47955)
CANYVAL-C 1U OBJECT G(47938) no reception continue to follow OBJECT G(47938)
CANYVAL-C 2U OBJECT G(47938) no reception continue to follow OBJECT G(47938)
BEESAT-5 OBJECT U(47950) OBJECT V(47951) Changed to follow OBJECT U(47950)
BEESAT-6 OBJECT U(47950) OBJECT V(47951) Changed to follow OBJECT U(47950)
BEESAT-7 OBJECT V(47951) OBJECT U(47950) Changed to follow OBJECT V(47951)
BEESAT-8 OBJECT V(47951) OBJECT U(47950) Changed to follow OBJECT V(47951)
CUBESX-SIRIUS-HSE OBJECT W(47952) OBJECT V(47951), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941) Rejected OBJECT U(47950)
CUBESX-HSE OBJECT V(47951) OBJECT U(47950), OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941)
ORBICRAFT-ZORKIY OBJECT X(47953) OBJECT W(47952), OBJECT Y(47954), OBJECT G(47938), OBJECT K(47941) Rejected OBJECT V(47951) and OBJECT Z(47955)
SIMBA OBJECT W(47952) OBJECT X(47953), OBJECT G(47938), OBJECT K(47941) Rejected OBJECT U(47950), OBJECT V(47951), OBJECT Y(47954) and OBJECT Z(47955)
GRBALPHA OBJECT G(47938) OBJECT W(47952), OBJECT X(47953), OBJECT K(47941) Rejected OBJECT V(47951) and change to follow OBJECT G(47938)
CHALLENGEONE OBJECT AA(47956) OBJECT U(47950) Rejected OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT Z(47955), OBJECT G(47938) and OBJECT K(47941)
KSU-CUBESAT OBJECT Y(47954) OBJECT Z(47955) Rejected OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941) and changed to follow OBJECT Y(47954)
6 Likes
63

I saw from SatNOGS observations that BCCSAT, that was launched with FEES satelite, is on 22R and well tracked, while FEES are still on 22N which is quite far. Can TLE of FEES be changed from object 22N to object 22Q or 22R?

Best Regards
Milo YT2CQ

64

I’ve updated to OBJECT R, but have in mind that it will not make any significant difference. The best way to see that is by using a software, like Gpredict, that shows the visibility from the ground. In this case as you can see in the image bellow whichever ground station tracks the one OBJECT will also track the other too as the actual difference of the rize/set time between the two OBJECT is some seconds:


1 Like
65

Latest update using ikhnos, which by the way has a new version. All the TLE sets are assigned to objects, however there are still missing ones:

Satellite Norad Follow Other Candidates Notes
UNISAT-7 OBJECT Q(47946) OBJECT J(47940),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947) Rejected TLE sets OBJECT H(47939), OBJECT N(47944), Changed to follow OBJECT Q(47946)
BCCSAT-1 OBJECT J(47940) OBJECT R(47947), OBJECT Q(47946) Changed to follow OBJECT J(47940)
FEES OBJECT N(47944) No reception changed to follow OBJECT R(47947)
DIY-1 OBJECT M(47943) No update
SMOG-1 OBJECT M(47943) Changed to follow OBJECT M(47943)
STECCO OBJECT M(47943) OBJECT H(47939), OBJECT J(47940), OBJECT N(47944),OBJECT P(47945), OBJECT Q(47946), OBJECT R(47947) No signal received since 2021-03-24 23:55. No update
NANOSATC-BR2 OBJECT U(47950) OBJECT V(47951) Rejected OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941), changed to follow OBJECT U(47950)
KMSL OBJECT U(47950) OBJECT V(47951), OBJECT W(47952), OBJECT X(47953), OBJECT Y(47954), OBJECT G(47938), OBJECT K(47941) No update
CANYVAL-C 1U OBJECT G(47938) No reception continue to follow OBJECT G(47938)
CANYVAL-C 2U OBJECT G(47938) No reception continue to follow OBJECT G(47938)
BEESAT-5 OBJECT U(47950) OBJECT V(47951) No update
BEESAT-6 OBJECT U(47950) OBJECT V(47951) No update
BEESAT-7 OBJECT V(47951) OBJECT U(47950) No update
BEESAT-8 OBJECT V(47951) OBJECT U(47950) No update
CUBESX-SIRIUS-HSE OBJECT V(47951) OBJECT U(47950) Added OBJECT U(47950), rejected OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941), changed to follow OBJECT V(47951)
CUBESX-HSE OBJECT W(47952) OBJECT X(47953), OBJECT G(47938), OBJECT K(47941) Rejected OBJECT V(47951), OBJECT U(47950), changed to follow OBJECT W(47952)
ORBICRAFT-ZORKIY OBJECT Y(47954) OBJECT G(47938), OBJECT K(47941), OBJECT Z(47955) Added OBJECT Z(47955), rejected OBJECT X(47953) OBJECT W(47952), changed to follow OBJECT Y(47954)
SIMBA OBJECT Y(47954) OBJECT X(47953), OBJECT G(47938), OBJECT K(47941) Added and changed to follow OBJECT Y(47954)
GRBALPHA OBJECT W(47952) OBJECT V(47951), OBJECT X(47953), OBJECT K(47941) Added OBJECT V(47951), rejected OBJECT G(47938) and change to follow OBJECT W(47952)
CHALLENGEONE OBJECT AA(47956) OBJECT U(47950) No update
KSU-CUBESAT OBJECT Y(47954) OBJECT Z(47955) Rejected OBJECT W(47952), OBJECT X(47953), OBJECT G(47938), OBJECT K(47941) and changed to follow OBJECT Y(47954)

We are missing several TLE sets, except from the current number of the sets which is less than the number of deployed satellites, there are several cases that we don’t have good fits. For example we miss at least two objects between OBJECT F and OBJECT M that will fit DIY-1 and SMOG-1.

Also in many cases we go back and forth on rejecting/adding objects, this is one more result of missing TLE sets, as current objects change their orbit parameters and fit(or not) the observations we have for each satellite.

Unfortunately we haven’t received again STECCO, however it seems that there is at least one unknown satellite that transmits at 435.805 and fits the TLE sets of this deployment. In some cases the signal looks almost the same with BCCSAT-1 and some other like CW or a simple carrier. We have created a satellite in DB with temporary NORAD ID 99719 to watch this satellite. Another possible satellite could be at 435.795 but we still need more observations to confirm it.

Some of the observation where the unknown satellite is visible:
https://network.satnogs.org/observations/3858176/
https://network.satnogs.org/observations/3858223/
https://network.satnogs.org/observations/3847755/
https://network.satnogs.org/observations/3856738/
https://network.satnogs.org/observations/3845478/
https://network.satnogs.org/observations/3847320/

2 Likes
66

Do you also use ikhnos against the analyst 88XXX objects?

2 Likes
